IPC2125LB-ASF40K-A - 5MP Bullet IR Camera, 4.0mm fixed lens, Smart IR 30m, Day/Night, Basic Sensor, DNR, IP67, SD slot, 3-Axis, PoE/DC12V

Specification Details Model / Series IPC2125LB-SF40-A (also “ASF” variant) — 5MP Fixed IR Mini Bullet Network Camera global.uniview.com +2 uniview-zahran.com +2 Sensor 1/3.0″ CMOS global.uniview.com +1 Max Resolution / Frame Rates • 5 MP (2592×1944) @ 20 fps • 4 MP (2560×1440) @ 20 fps • 3 MP (2304×1296) @ 20 fps • 1080p (1920×1080) @ 30/25 fps (or 30 fps) global.uniview.com +1 Minimum Illumination Colour: 0.01 lux (F2.1, AGC ON); 0 lux with IR on global.uniview.com +1 Lens / Optics / IR Specification Details Lens Fixed 4.0 mm, F2.1 global.uniview.com +1 Field of View (4.0mm version) Horizontal ~79.0°, Vertical ~42.3°, Diagonal ~85.1° global.uniview.com +1 IR / Night Vision Smart IR; IR range up to ~30 m (≈ 98 ft) global.uniview.com +1 IR Wavelength 850 nm global.uniview.com Image / Processing Specification Details Image Correction / Noise Reduction 2D & 3D Digital Noise Reduction (DNR) global.uniview.com +1 Day/Night IR-cut filter with auto switch (ICR) global.uniview.com +1 Other Image Features BLC (Backlight Compensation), HLC (High Light Compensation), Defog (digital), etc. global.uniview.com Video / Streams / Compression Specification Details Video Compression Ultra265, H.265, H.264, MJPEG global.uniview.com +1 Bit Rate 128 Kbps to 6144 Kbps global.uniview.com +1 Streams Dual streams (main + sub) global.uniview.com +1 Interfaces & Network Specification Details Power Options PoE (IEEE 802.3af) and DC 12 V ±25% global.uniview.com +1 Network 1 × RJ45, 10/100 Mbps Ethernet global.uniview.com Protocols / Standards ONVIF (Profile S, Profile T), TCP/IP, RTSP, HTTPS, etc. global.uniview.com +1 Physical & Environmental Specification Details IP Rating IP67 — protected from dust and immersion to a depth of 1m under defined conditions global.uniview.com +1 Operating Temperature / Humidity -30 °C to +60 °C; Humidity ≤ 95% RH, non-condensing global.uniview.com +1 Dimensions / Weight ~161 × 63 × 62 mm; weight ~0.36 kg (approx) global.uniview.com +1 Mount Adjustments 3-axis (Pan 0-360°, Tilt 0-90°, Rotate 0-360°) global.uniview.com Storage & Other Features Specification Details SD Card / Edge Storage Supports microSD card (capacity up to typical values in similar models; for “AF40K-DL” version supports higher, but in your “SF40-A” version check exact limit) global.uniview.com +2 TriStar Security Products +2 Surge Protection 4 kV global.uniview.com +1

SAR 219.00

SKU: GS20250924
